CONICAL SPRING MECHANICAL SEAL
Leading Manufacturer of Conical Spring Mechanical Seals
Seal Max Sealing Solution offers high-quality conical spring mechanical seals for pumps, compressors, and other rotating equipment. These pusher-type mechanical seals are designed for dependable leakage control in water, light chemical, utility, and general industrial applications.
Conical spring mechanical seals are compact, cost-effective, and suitable for plain or stepped shafts depending on the seal design. They are available in balanced and unbalanced configurations to suit different pressure, temperature, and operating requirements.
Products Category
Contact Info
Address:
Seal Max Sealing Solution
A-130, Orchid Complax, Pirojpura Road, Chhapi, (gujarat) 385210
+(91) 8200817992
24/7 Support for Your Business
Info File
Quality Assurance
Available Material Options
| Component | Material Options |
|---|---|
| Rotary and Stationary Faces | Carbon, carbon antimony, ceramic, silicon carbide, tungsten carbide and cast CrMo steel |
| Secondary Seals | NBR, EPDM, Viton, silicone, PTFE and Aflas |
| Hardware and Spring | SS 304, SS 316, Hastelloy-C, Alloy 20 and other suitable grades |
Conical Spring Mechanical Seal Product Details
| Property | Details |
|---|---|
| Product Name | Conical Spring Mechanical Seal |
| Seal Type | Pusher-type mechanical seal |
| Design Options | Balanced and unbalanced configurations |
| Shaft Type | Suitable for plain shafts and stepped shafts |
| Spring Design | Rotating conical spring design |
| Seal Arrangement | Single mechanical seal |
| Rotation | Available according to equipment rotation direction |
| Applications | Pumps, compressors, circulation pumps and industrial rotating equipment |
| Suitable Media | Water, wastewater, light chemicals, process fluids and utility fluids |
| Customisation | Available as per shaft size, pump model, pressure, temperature and fluid type |
Typical Operating Range
| Operating Parameter | Available Range |
|---|---|
| Shaft Diameter | Available for various shaft sizes as per seal model and equipment requirement. |
| Pressure | Suitable for standard to high-pressure industrial applications. |
| Temperature | Suitable for low- to high-temperature operating conditions. |
| Sliding Velocity | Designed for stable operation at suitable pump and equipment speeds. |
| Seal Design | Balanced or unbalanced, depending on pressure and process conditions. |
Why Choose Seal Max Sealing Solution?
Seal Max Sealing Solution provides reliable conical spring mechanical seals with suitable material combinations for different industrial fluids and operating conditions. We offer application-based seal selection according to shaft diameter, pump model, pressure, temperature, RPM, and process media.
Our team supports customers with standard and customised mechanical seal solutions to help reduce leakage, improve equipment reliability, and lower maintenance downtime.
Fill Up the Form For Domestic & Export Inquiry !
Fill out the form and a member from our sales team will get back to you within 5 hours, or scroll down for more ways to get in touch.
